Monel K500 (UNS N05500) Plates/Sheets/Coils Importer, Vendor, & Stockist
Nickel Alloy Plate Hub is a trusted stockist and direct importer of Monel K500 Plates, Sheets, and Coils, sourced from a reputed supplier in South Mumbai, India. We feel proud, as we have a presence throughout the globe and are the most widespread exporter, provider, dealer, and trader of Monel K500 Plates, Sheets and Coils in India and throughout the globe.
Many are looking for the exotic grades, which will improve their productivity and build their brand. We are here for your exotic quality needs, such as the many requests for the Monel K500 Plates in India.
Monel K500 Plates / Sheets / Coils Specifications
| Parameter | Specification |
|---|---|
| Specifications | ASTM B127 / ASME SB127 |
| Dimension Standard | ASTM, ASME, EN, DIN, JIS, GB, etc |
| Width | 1000 mm, 1250 mm, 1500 mm, 2000 mm |
| Length | 2000 mm, 2500 mm, 3000 mm, 6000 mm or coil form |
| Thickness | 1 mm to 36 mm |
| Form | Plates, Sheets, Coils, Plain Sheet, Perforated Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Surface Finishing | Hot Rolled Plate (HR), Cold Rolled Sheet (CR) |
| UNS Number | UNS N05500 |
| Werkstoff Nr. | 2.4375 |
| Origin | VDM, Nippon Yakin Japanese Origin |
Monel K500 Plates / Sheets / Coils
Monel K-500, a grade from the Monel family. It is a nickel-copper alloy and a combination of alloys that especially consists of the mixture of aluminium & titanium. It is found to be precipitation-hardened to deliver high strength and hardness compared to the other grades, which are of the Monel family, i.e., category 400. It offers fantastic corrosion resistance, uniquely in marine and chemical environments, making it ideal for demanding industrial applications.
Monel K500 Sheets & Plates show many similarities to the corrosion resistance of Monel 400, with refined mechanical factors, such as higher tensile strength and optimal wear resistance.
Common Types of Monel K500 Alloy Plates / Sheets / Coils
- Monel K500 Hot Rolled Plate
- Monel K500 Cold Rolled Sheet
- Monel K500 Slit Coils
- Monel K500 Plain Plates
- Monel K500 Perforated Sheets
We maintain a huge inventory of WNr 2.4375 Plates / Sheets / Coils Stockists & Supplier, available in standard and custom dimensions.
Mechanical Features of Monel K500 Plates / Sheets / Coils
| Property | Value |
|---|---|
| Density | 8.44 g/cm³ |
| Melting Range | 1315–1350 °C |
| Specific Heat | 0.427 J/g-°C |
| Electrical Conductivity | 3.4% IACS |
| Modulus of Elasticity | 179 GPa |
| Magnetic Properties | Slightly Magnetic when cold worked |
Price of Monel K-500 Plates / Sheets / Coils
The pricing of Monel K500 Sheets, Plates, and Coils relies upon thickness, length, finishing, and many other criteria. Products are sourced from reliable and reputed suppliers, generally tend to be top-class because of their fantastic excellence and expertise in the field. Our plates are one of the best and most low-priced, making them perfect for large-scale industrial applications in India.
Monel K500 Plates/Sheets/Coils – Chemical Composition
| Element | Percentage (%) |
|---|---|
| Nickel (Ni) | 63.0 min |
| Copper (Cu) | 27.0 – 33.0 |
| Aluminum (Al) | 2.30 – 3.15 |
| Titanium (Ti) | 0.35 – 0.85 |
| Iron (Fe) | 2.0 max |
| Carbon (C) | 0.25 max |
| Manganese (Mn) | 1.5 max |
| Silicon (Si) | 0.5 max |
| Sulfur (S) | 0.01 max |
Industrial Use & Applications of Monel K500 Plates / Sheets / Coils
- Marine Construction: Shafts, propellers, fasteners
- Oil & Gas: Downhole tools, valves, pump components
- Chemical Processing: Pumps, reactors, and piping systems
- Aerospace: Fasteners, turbine blades
- Expertise Plants: Heat exchangers, condensers
- Defence & Naval Applications
Our UNS N05500 Plates Supplier in India division ensures ready stock and delivery to everything vital sectors, tailored to project specifications.
Mechaincal Characteristics of Monel K500 Plates / Sheets / Coils
| Property | Value |
|---|---|
| Tensile Strength | 965 MPa min |
| Yield Strength | 690 MPa min |
| Elongation | 20% min |
| Hardness (Rockwell) | 22 – 35 HRC |
Why Is Exotic Plate Hub the Top Choice?
- Grandest Stockist & Exporter of Monel K500 Plates in India
- Trusted Monel K500 Plates Dealer & Supplier
- Sourced from Outokumpu (Europe) and Nippon Yakin (Japan)
- Custom Cutting, Finishing & Testing Services
- 24/7 Copy and Worldwide Delivery
- Competitive Prices and Fastest Turnaround Times
We are the best WNr 2.4375 Plates / Sheets / Coils Exporter, offering best-in-class resolutions for everything your alloy plate needs.
CONTACT US FOR AFFORDABLE PRICES
Equivalent Grades of Monel K500 Plates / Sheets / Coils
| Standard | Grade |
|---|---|
| UNS | N05500 |
| Werkstoff Nr. | 2.4375 |
| ASTM | B127 |
| EN | NiCu30Al |
| JIS | NW5500 |
CONTACT US TODAY FOR MORE DETAILS OF MONEL K500 PLATES ,SHEETS & COILS!
Whether you’re seeking a reliable Monel K500 (UNS N05500) Plates Supplier or a global WNr 2.4375 Sheets & Coils Stockists & Supplier, Nickel Alloy Plate Hub is your one-stop destination. Our commitment to quality, rightness, and client satisfaction has made us the preferred choice for critical industries.
FAQs
What is Monel K-500 used for?
It’s used in marine, oil & gas, chemical, and aerospace applications for its strength and corrosion resistance.
What is the difference between Monel 400 and K-500?
Monel K-500 has higher strength and hardness due to age-hardening, while both offer similar corrosion resistance.
Is Monel K-500 corrosion-resistant in seawater?
Yes, it resists seawater corrosion, pitting, and stress corrosion cracking.
Can Monel K-500 be machined and welded?
Yes, it can be machined and welded with proper techniques.
What are the key properties of Monel K-500?
High strength, excellent corrosion resistance, and good performance in extreme temperatures.
