Nickel 200 (UNS N02200)- Plates / Sheets / Coils Stockist, Exporter, & Importer
Nickel Alloy Plate Hub is a trusted stockist and direct importer of Nickel 200 Plates, Sheets, and Coils, sourced from a reputed supplier in South Mumbai, India. Nickel 200 (UNS N02200) – Plates / Sheets / Coils is essentially developed from commercial terms pure wrought nickel alloy. Typically, it offers fantastic mechanical qualities, remarkable corrosion resistance, and awesome thermal and electrical conductivity. They are specifically designed using 99.6% pure nickel for applications requiring resistance to caustic alkalis and acidic environments. A major reason why they are used across a wide range of industries, including chemical processing, electronics, food handling, and marine engineering.
Nickel 200 / UNS N02200 Plates / Sheets / Coils Specification:
Every specification detail of Nickel 200 Plates / Sheets / Coils that you need to know about is given in the table below:
| Parameter | Specification |
|---|---|
| Specifications | ASTM B162 / ASME SB162 |
| Dimension Standard | ASTM, ASME, EN, DIN, JIS, GB, etc |
| Width | 1000 mm, 1250 mm, 1500 mm, 2000 mm |
| Length | 2000 mm, 2500 mm, 3000 mm, 6000 mm or coil form |
| Thickness | 1 mm to 36 mm |
| Form | Plates, Sheets, Coils, Plain Sheet, Perforated Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Surface Finishing | Hot Rolled Plate (HR), Cold Rolled Sheet (CR) |
| UNS Number | UNS N02200 |
| Werkstoff Nr. | 2.4066 |
| Origin | VDM, BOHLER |
What are Nickel 200 Plates / Sheets / Coils?
It is from Nickel 200 that Nickel 200 Plates / Sheets / Coil are supplied. Typically, they are produced using a process called ‘Flat Rolling’. They are renowned for their excellent mechanical properties and superior resistance to corrosive environments. For example, those that involve use of ‘Alkalis’.
More importantly, Nickel 200 Plates / Sheets / Coil are used in a wide range of industries because of their purity, strength, and resistance to aggressive environments.
Types of Nickel 200 or UNS N02200 Plates/Sheets/Coils:
There are a few types of Nickel 200 (UNS N02200) that are available. They are as follows:
- Nickel 200 Hot Rolled Plate
- Nickel 200 Cold Rolled Sheet
- Nickel 200 Slit Coils
- Nickel 200 Plain Plates
- Nickel 200 Perforated Sheets
Price List of Nickel 200 / UNS N02200 / WNR 2.4066 Plates / Sheets / Coil:
The Nickel 200 (UNS N02200) WNR 2.4066 Plates / Sheets / Coil that we at Nickel Alloy Plate Hub offer will depend on a variety of factors. Typically, they include quantity, thickness, finish, supplier, and market fluctuations in raw nickel prices. So, if you intend to buy Nickel 200 (UNS N02200) WNR 2.4066 Plates / Sheets / Coil of 100% Premium Quantity
Nickel 200 Plates / Sheets / Coils Mechanical Properties Table:
The information of Nickel 200 Plates / Sheets / Coils and their mechanical properties are given below in a table:
| Property | Value |
|---|---|
| Tensile Strength (min) | 380 MPa / 55 ksi |
| Yield Strength (0.2% Offset, min) | 105 MPa / 15 ksi |
| Elongation (min) | 45% |
| Hardness (Rockwell B) | 60 |
| Modulus of Elasticity | 207 GPa / 30 × 10⁶ psi |
| Melting Point | 1446 °C / 2635 °F |
| Density | 8.89 g/cm³ / 0.321 lb/in³ |
| Poisson’s Ratio | 0.31 |
Industrial Applications of Nickel 200 /WNR 2.4066 Plates / Sheets / Coil :
Renowned by its Werkstoff number WNR 2.4066, Nickel 200 is widely used in a variety of industries. This is mainly because of their excellent mechanical properties and high resistance to a wide range of corrosive environments. Some of them are as follows:
- Electronics and Electrical Industry
- Chemical Processing Industry
- Food Processing Industry
- Aerospace and Defense
- Petrochemical and Oil & Gas Industry
- Heat Treatment and Furnace Applications
- Pharmaceutical Industry
- Automotive Industry
- Synthetic Fiber Production
Nickel 200 Plates / Sheets / Coils Chemical Composition Table:
Some of the critical chemical components of Nickel 200 Plates / Sheets / Coils are given below:
| Element | Composition (%) |
|---|---|
| Nickel (Ni) | ≥ 99.0 |
| Iron (Fe) | ≤ 0.40 |
| Manganese (Mn) | ≤ 0.35 |
| Carbon (C) | ≤ 0.15 |
| Silicon (Si) | ≤ 0.35 |
| Sulfur (S) | ≤ 0.01 |
| Copper (Cu) | ≤ 0.25 |
Why Choose Us for Nickel 200 (UNS N02200) Plates / Sheets / Coil?
It is a fact that when seeking to source 100% Premium Nickel 200 (UNS N02200) you shall find that Nickel Alloy Plate Hub is one of the leading Nickel 200 (UNS N02200) supplier in India that truly stands out. The reasons are as follows:
- Wide range of sizes and customization availability
- Provision of Premium Material
- Third Party Testing and Certification
- Fast and Efficient Delivery
- Competitive Pricing
- Excellent Technical Support
Get a FREE Quote today
Equivalent Grades of Nickel 200 or UNS N02200 Plates / Sheets / Coil:
| Standard | Equivalent Grade |
|---|---|
| UNS | N02200 |
| WNR (Werkstoff Nr.) | 2.4066 |
| ASTM | B162, B161, B163, B725 |
| EN | 2.4066 |
| DIN | Ni 99.2 |
| BS (British Standard) | NA 11 |
| JIS (Japan) | NW 2200 |
| AFNOR (France) | N-100M |
| ISO | Ni ≥ 99.0% (ISO 6208) |
CONTACT OUR HUB FOR MORE INFORMATION
Get a Free Consultation Now
Are you seeking Nickel 200 (UNS N02200) Plates / Sheets / Coil at an affordable price? If yes then come visit us at Nickel Alloy Plate Hub, a top Nickel 200 (UNS N02200) Plates/Sheets/Coils Supplier in India now and ‘Get a Quote’ today.
FAQs
What is Nickel 200 used for?
Nickel 200 plates are widely used in electrical, chemical, and food processing industries due to their excellent electrical conductivity and resistance to corrosive environments.
Is Nickel 200 corrosion-resistant?
Yes, Nickel 200 sheets and coils offer excellent resistance to alkalis and neutral or mildly oxidizing solutions, making them suitable for caustic handling equipment.
What makes Nickel 200 different from other nickel alloys?
Nickel 200 is a commercially pure wrought nickel with high ductility and thermal conductivity, ideal for applications requiring low gas content and magnetic properties.
